HA30A Articulated hauler

HA30A Articulated Dump Truck

HA30A

The new Hyundai HA30A is the ultimate ADT for all your quarrying, mining and earthmoving needs. Thanks to its tandem rear axle and independent front wheel suspension, it’s perfect for working in tough ground conditions like yours.

276 kW

17.8 cubic meter

1876 Nm

28 to

Technical details

Product Overview

The new Hyundai HA30A A-Series ADT delivers the ultimate in manoeuvrability, safety, comfort and low cost in a highly productive 30 tonne machine. Based on a proven design with 50 years heritage, it has many features that sets it apart. A tandem rear axle and independent front wheel suspension makes it more manoeuvrable, safe and comfortable, while a sloping rear frame that guides loads to the front, increases traction for greater productivity. With ground level service access and one of the biggest cabs in the industry, the HA30A fits perfectly alongside our large excavator and wheel loader A-Series machines.

Reasons to choose the HA30A



Greater manoeuvrability

A more manoeuvrable machine is a more productive machine, especially in tough conditions and nothing covers more ground than a Hyundai ADT.

  • The turning ring is located in front of the articulation point, ensuring equal weight distribution to the front wheels, allowing greater turning capability.
  • A tandem rear axle gives a massive 40% rotation to give unbeatable performance, traction and ground engagement over rough ground.
  • Independent front wheel suspension allows free movement up front so that obstacles don’t affect the back suspension or axles.
  • A sloping rear frame guides loads to the front, increasing traction and providing a lower centre of gravity for greater stability.

Hyundai HA45A Articulated Dumper Truck (ADT) front view

Lower cost of ownership

Lower your total cost of ownership, thanks to a combination of world-class components and a design that reduces servicing and maintenance needs.

  • One rear differential and a simple driveline result in less moving parts, for easier and lower cost maintenance.
  • A sloping chassis keeps more fluid or wet materials including gravel inside the tipping body.
  • A less than 3-metre width means the machines can be easily moved from one site to another on a shorter low loader to save transport costs.
  • Auto grease system saves you the time and trouble of lubricating by hand.
  • Equal weight distribution ensures the same load on every tyre and so, less wear.
  • Proven Stage V engine delivers high torque at low revs with low fuel consumption.
HA30A ADT in the snowfields

Exceptional comfort & ease of use

The most spacious cab in the industry and easy-to-use controls, provide the perfect office environment for long hours working in some of the toughest conditions.

  • Climate control and a high-quality operator seat make for a comfortable and productive operator.
  • Precise steering, good visibility, low noise levels and optional vertical movement, provide additional comfort and quiet.
  • Convenient 7" LCD colour display panel shows all the important control and safety information.
  • An electronically managed body hoist lever is easy to operate with fingertip control.
  • An anti-vibration rubber cab suspension increases comfort and reduces noise.
Hyundai HA45A ADT cabin interior

Ultimate productivity

When work is a non-stop production line, you need machines that perform reliably, day in, day out. Hyundai ADTs are designed to increase productivity whatever the conditions.

  • A tandem rear axle gives a massive 40% rotation to give unbeatable performance and traction over rough ground.
  • Best-in-class ground clearance and ground bearing pressure for more productive working.
  • Our self-leveling, hydro-gas front suspension system provides outstanding performance in rough terrain.
  • Well positioned controls and high-quality seat mean a more productive operator.
  • Upgraded monitor and control panel provide all the information to stay productive.
  • A sloping chassis keeps more materials inside the tipping body to save time and money.
Hyundai HA45 Dumping rocks

FAQs about the HA30A ADT


Does the HA30A comply with the European stage V emission levels?

Yes. The HA30A complies with Stage V of emission regulation

(EU) 2016/1628.


What type of transmission is used on the HA30A?

Electronically-controlled automatic transmission with retarder, Full-time 6 × 6 drive with two transverse differentials and one longitudinal Inter-axle longitudinal, Torque-proportioning differential, integrated into the ZF transmission Front Axle Transverse Differential


Does the HA30A have air conditioning?

Yes, both the HA30A and the HA45A come with air conditioning.



What is the tipping angle of the HA30A?

70°
